Industrial Pump System
A centrifugal pump assembly designed for continuous-duty industrial service, with impeller geometry refined through fluid dynamics simulation.
Challenge
Improving flow efficiency without increasing the pump's physical footprint or complicating maintenance access.
Approach
Built the full assembly in Siemens NX, then worked with simulation results to iterate impeller and volute geometry across several design passes.
Project Images
Tools Used
Siemens NX
CFD Prep
Assembly Design
Production Documentation
Results
- ✓Improved flow efficiency by 12%
- ✓No change to mounting footprint
- ✓Simplified maintenance access to wear parts
